GANTRY MILLING MACHINE ENDURA® 900LINEAR COMPACT

High structural rigidity, highest dynamics and accuracies

Gantry Milling Machine ENDURA® 900LINEAR Compact

The ENDURA® 900LINEAR Compact is a heavy-duty, state-of-the-art linear motor milling machine in compact GANTRY design with 5 CNC-controlled simultaneous axes, particularly suitable for efficient 5-sided finishing of workpieces made of aluminum, cast iron and steel.

Features, technology and equipment:

  • Highly dynamic overhead GANTRY tool milling machine in compact design:
    Gantry moving in X-direction.
  • Design of the machine:
    Machine bed made of solid cast iron, side walls (X-axis), cross slide, walking beam (Z-axis) and portal
    (Y-axis) as extremely rigid, yet weight-optimized welded steel construction.
  • No foundation necessary:
    Due to the inherently rigid machine bed, a standard industrial floor, approx. 11,8" thick, steel-reinforced, is sufficient for the installation; a special foundation, is not required. The machine is set up and aligned by fixators bolted to the hall floor.
  • Drive technology of linear axes:
    Water-cooled linear motors in the linear axes (X, Y and Z), X axis designed as a GANTRY axes pair.



  • Direct measuring systems:
    The linear and rotary axes are equipped with direct measuring systems.
  • Z-axis weight compensation:
    Highly dynamic pneumatic cylinders support the Z-axis drive.
  • Direct measuring systems:
    The linear and rotary axes are equipped with direct measuring systems.
  • Linear axes guides:
    The linear axes are equipped with hardened and ground, backlash-free pre-tensioned guide elements.
  • Thermal decoupling:
    Coating and cladding of relevant structural components with suitable insulation material and sheet metal. Negative influences of external temperature fluctuations on the positioning accuracy of the machine are significantly reduced through thermal decoupling.



Highly dynamic by the use of linear motors

Rigid machine system - highly damping structural elements

Kompakt-Portalfräsmaschine ENDURA® 900LINEAR

Advantages at a glance.

  • Large machining area
  • Small installation surface
  • Can be set up without foundation
  • Direct drive motors in all axes (linear and torque motors)
  • High structural rigidity, highest dynamics and accuracies
  • Thermal decoupling of short-term temperature fluctuations by Thermo Guard
  • Travels up to 354.3" x 137.8" x 59.1"
  • Range of materials: steel, cast iron and aluminum

Gantry Milling Machine
ENDURA® 900LINEAR Compact

Compact gantry milling machine with large machining area and small footprint.

Traverse paths

X-axis: 98.4" / 157.5" / 216.5"

Y-axis: 137.8"

Z-axis: 59.1"



Feed rates

X-axis: 0.197"/min - 2,559.1"/min

Y-axis: 0.197"/min - 2,559.1"/min

Z-axis: 0.197"/min - 2,559.1"/min



Acceleration up to 137.8"/sec²



Position accuracy

X-axis:  0.0006"

Y-axis:  0.0006"

Z-axis:  0.0006"



Position scatter

X-axis: 0.0004"

Y-axis: 0.0004"

Z-axis: 0.0004"



Inherently rigid compact machine with closed machine bed

Wear-free, highly dynamic linear motors in all linear axes (X, Y and Z)

Direct measuring systems in all axes (X, Y, Z, C and A)

Safety systems and brakes in all linear axes (X, Y and Z)

Drive units consistently protected by bellows

Automatic tool changing systems

Minimum quantity spray dosing system

Coolant systems (wet operation)

Tool measuring systems

Workpiece measuring systems

Chips and dust disposal systems

Plane cover / Sound insulation enclosure
